List of Errata in Catalogue

Japanese General Catalogue Friends No.216
Published in June 2015 / List of errata in the latest Japanese catalogue.

Please check the details.
Last Updated: 2018.12.06
ページ Product Location Point Wrong Correct Last Update
13 Q-LOCK ELEMENTS/PINS (SCREW TYPE)  Specifications G dimensions of QLT26CP 25 24 2017.04.05
13 Q-LOCK ELEMENTS/PINS (SCREW TYPE)  Specifications G dimensions of QLTF26CP 25 24 2017.04.05
14 Q-LOCK ELEMENTS/PINS (SCREW TYPE)  Specifications G dimensions of QLTS26CPV 25 24 2017.04.05
19 Q-LOCK ELEMENTS PINS (PNEUMATIC TYPE SINGLE ACTION) Section Drawing Please click a right icon. 2015.10.23
20 Q-LOCK ELEMENTS PINS (PNEUMATIC TYPE DOUBLE ACTION) Mounting Dimensions E dimensions of QLA19D 19.5 19 2015.12.02
21 Q-LOCK ELEMENTS PINS (PNEUMATIC TYPE DOUBLE ACTION) Section Drawing Please click a right icon. 2015.10.23
26 Q-LOCK ELEMENTS BUSHES (PNEUMATIC TYPE) Mounting Dimensions Please click a right icon. 2015.10.23
26 Q-LOCK ELEMENTS BUSHES (PNEUMATIC TYPE) Mounting Dimensions I dimensions of QLA19 & QLA26 M6 Rc1/16 2018.12.06
26 Q-LOCK ELEMENTS BUSHES (PNEUMATIC TYPE) Mounting Dimensions I dimensions of QLA32 M10 Rc1/8 2018.12.06
28 Q-LOCK ELEMENTS BUSH COVER (PNEUMATIC TYPE) Mounting Dimensions Please click a right icon. 2015.10.23
29 Q-LOCK ELEMENTS/BUSHES (HYDRAULIC TYPE) External Dimensions Please click a right icon. 2015.10.26
32 PLATE WITH Q-LOCK ELEMENTS (FLAT) Specifications Title Locating Pin Locate bush 2015.11.04
32 PLATE WITH Q-LOCK ELEMENTS (FLAT) Specifications Title Clamp Pin Clamp Bush 2015.11.04
33 PLATE WITH Q-LOCK ELEMENTS (WITH MACHINE VISES) Specifications Title Locating Pin Locate bush 2015.11.04
33 PLATE WITH Q-LOCK ELEMENTS (WITH MACHINE VISES) Specifications Title Clamp Pin Clamp Bush 2015.11.04
34 PALETTE TABLE WITH BUILT-IN Q-LOCK ELEMENTS Material Plate: FC250 Plate: S50C 2015.11.05
35 PLATE WITH Q-LOCK ELEMENTS (FLAT) Material Plate: FC250 Plate: S50C 2015.11.05
35 PLATE WITH Q-LOCK ELEMENTS (FLAT) Specifications Title Locating Pin Locate bush 2015.11.05
35 PLATE WITH Q-LOCK ELEMENTS (FLAT) Specifications Title Clamp Pin Clamp Bush 2015.11.05
40 2 FACES/MC TOOLING BLOCKS WITH Q-LOCK ELEMENTS (SIDE) Specifications Please click a right icon. 2015.08.18
41 ATTACHMENT PLATE FOR 2-FACE ANGLE PLATES (FLAT) Specifications Please click a right icon. 2015.08.18
42 ATTACHMENT PLATE FOR 2-FACE ANGLE PLATES (WITH MAGNETIC CHUCKS) Specifications Title Locating Pin Locate bush 2015.11.09
42 ATTACHMENT PLATE FOR 2-FACE ANGLE PLATES (WITH MAGNETIC CHUCKS) Specifications Title Clamp Pin Clamp Bush 2015.11.09
82 CONTROLLERS Specifi cations and External Dimensions ST200F Weight (kg) 5.9 8.1 2015.07.15
82 CONTROLLERS Power supply 200 V AC single phase 50/60 Hz AC200V 50/60 Hz 2018.02.23
85 MAGNETIC SELF-CUT PLATE Accessories Attachment bolt MBX10 M8X10 2015.06.22
94 MULTI AUTO CLAMPS - GUIDE BAR TYPE [SERIES TYPE] Component Parts Clamp pin (output) 1 2 2016.01.26
95 MULTI AUTO CLAMPS - GUIDE PLATE TYPE [SERIES TYPE] Component Parts Clamp pin (output) 1 2 2016.01.26
96 MULTI AUTO CLAMPS - DOUBLE-SIDED TYPE [BRANCH TYPE] Component Parts Clamp pin (output) 1 2 2016.01.26
101 WEDGE CLAMPING LOCATING BLOCK Specifications B dimensions of DKC-08RBH 38 45 2015.08.18
102 Specifications for Movable Part KSC12-VJ KCS12-VJ 2015.06.22
148 GAS SPRING Specifications Please click a right icon. 2016.04.11
150 GAS SPRING(FREE MOUNTING ANGLE TYPE) Specifications h dimensions of GS2307&GS2308&GS2309 289.5 288.5 2016.04.11
150 GAS SPRING(FREE MOUNTING ANGLE TYPE) Specifications h dimensions of GS4507&GS4508&GS4509 371.5 369.5 2016.04.11
165 LOW-FLOOR TYPE VIBRATION ISORALTED PLATES Mitsutoyo Specifications Order No. of VLS3045HD-SJ411 120928 120298 2016.03.17
166 VIBRATION ISOLATION BASES External Dimensions A B 2016.09.05
166 VIBRATION ISOLATION BASES External Dimensions B A 2016.09.05
174 HANDLE JOINT/CHIP COVER Handle Joint/Specifications Compatible Models Common to all CV models Common to CV-H,TH models 2018.02.14
178 LOCK-TIGHT FA QUICK ONE MACHINE VISES Size Chart B dimensions of LTFV100Q 483.5 484 2017.09.13
178 LOCK-TIGHT FA QUICK ONE MACHINE VISES Size Chart B dimensions of LTFV,LTFH125Q 560 567 2017.09.13
178 LOCK-TIGHT FA QUICK ONE MACHINE VISES Size Chart B dimensions of LTFV,LTFH150Q 700 699 2017.09.13
178 LOCK-TIGHT FA QUICK ONE MACHINE VISES Size Chart B dimensions of LTFV,LTFH175Q 741 740 2017.09.13
190 LOCK-TIGHT 5 AXIS MACHINE VISES Size Chart M dimensions of LT5AU75 2 4 2016.01.13
190 LOCK-TIGHT 5 AXIS MACHINE VISES Size Chart AC dimensions of LT5AU75 48 50 2016.01.13
190 LOCK-TIGHT 5 AXIS MACHINE VISES Specifications Clamping Force of LT5AU75 15 16 2016.01.13
190 LOCK-TIGHT 5 AXIS MACHINE VISES Accessories LT5AU100(M):Standard handle LT-13HN250, LT-13HN370 LT-12HN250, LT-12HN370 2018.12.06
192 LOCK-TIGHT 5 AXIS MACHINE VISES Size Chart AA dimensions of LT5AU75FM 31 56 2016.01.13
194 LOCK-TIGHT 5 AXIS MACHINE VISES ACCESSORIES Specifications Compatible Vises of LT5AU100-SJG4 LT5AU-100(M,FM,F) LT5AU-100(M,FM,F),LT5AU125F 2018.10.17
194 LOCK-TIGHT 5 AXIS MACHINE VISES ACCESSORIES Specifications Compatible Vises of LT5AU100-SJG6 LT5AU-100(M,FM,F) LT5AU-100(M,FM,F),LT5AU125F 2018.10.17
194 LOCK-TIGHT 5 AXIS MACHINE VISES ACCESSORIES Specifications Compatible Vises of LT5AU100-SJG8 LT5AU-100(M),100F(M) LT5AU-100(M,FM,F),LT5AU125F 2018.10.17
196 LOCK-TIGHT 5 AXIS MACHINE VISES ACCESSORIES Set Contents Base ... 1 piece Round jaw plate (flat, grid) ... 2 pieces (either type) Hex bolt M8 × 16 ... 2 pieces Low head socket cap bolt M8 × 15 ... 2 pieces Base ... 2 piece Round jaw plate (flat, grid) ... 4 pieces (either type) Hex bolt M8 × 16 ... 4 pieces Low head socket cap bolt M8 × 15 ... 4 pieces 2015.08.07
198 PULL DOWN FREE JAW VISES Accessories PV1,PV2:T-slot Bolt Compatible T-slot 14.18 Compatible T-slot 18 2018.05.30
206 MACHINE VISE SERIES ACCESSORIES Specifications Compatible Models of LTGB12-14 - LTFV75 addition 2016.05.11
206 MACHINE VISE SERIES ACCESSORIES Specifications Compatible Models of LTGB18-14 LTFV75、E-9173 ETO-THタイプ全機種、SV-56、LT5AU(F,FM) LTFV75、E-9173 ETO-TH type (All)、SV-56 2016.07.29
206 MACHINE VISE SERIES ACCESSORIES Specifications Compatible Models of LTGB16-14 LTFV75、E-9173 ETO-TH type (All)、SV-56 2016.07.29
212 QUICK ACTION DRILL PRESS VISES ACCESSORIES Compatible Models of 930969 EVS,ETPA ETS,ETPA 2016.10.12
225 GRANITE SURFACE PLATES Size Chart Weight of GP06090 182.0 196 2018.01.26
233 HAMMER SURFACE PLATES FOR SHEET METAL Specifications Number of Ribs of T13 1X1 2X2 2018.02.26
234 VEE BLOCKS TYPE A Size Chart Please click a right icon. 2017.03.02
235 VEE BLOCKS TYPE B Size Chart Please click a right icon. 2017.03.02
